China Golf car 48V5KW motor 48V400-450Ah controller grade abilisty 25%

China Golf car 48V5KW motor 48V400-450Ah controller grade abilisty 25%

golf cart dash organizer

golf cart dash tray

Place of Origin:

CHINA

Brand Name:

TOP GOLF

Certification:

CE

Model Number:

EV.2+2G

Contact Us
Request A Quote
Product Details
Speed:
25mph
Distance Mileage:
68.5mile
Grade Ability:
25%
Brake Distance:
<3.5
Charging Time:
6-8 Hours
Weight:
575
Front Suspension:
Double A Arm
Bumper:
Front Steel Bumper
Tyre:
22*10-14
Battery:
Lead Acid Battery/lithium Battery
Motor:
4-5kw
Charger:
48V20A
Controller:
48V400-450A
Lighting System:
LED Front Combination Lights (low Beam,high Beam,turn Signals,daytime Running Lights,position Lights )
Payment & Shipping Terms
Minimum Order Quantity
1 PCS
Price
negotiable
Packaging Details
Cartoon Package
Delivery Time
10-15 WORK DAYS
Payment Terms
L/C, T/T, Western Union
Supply Ability
10000 PCS
Product Description

Electric Golf Cart Customizable Color High-End Upgradeable

Description


Model No.:EV 2+2G
Charger:computer intelligent charger
Motor:48V/4KW
Battery:Chaowei battery,8V*6
Transaxle:12.31:1
Overall Size:2970*1200*1880mm
Ground clearance:170mm
Tread distance:front900/rear1000mm
Net weight:575kg
Loading:4 people


Optional Spare Parts

Speaker, Underbody lighting,side step,front clay basket,seats cover, security light,cargo box, rear canopy, ice box, caddie plate, body cover,
rain cover, sun curtains, sand rake, sand box, speed meter


Performance


Body and Frame
Frame (Chassis)Welded steel framework, with anti-rust treatment of acid washing, phosphating and electro-coating
Body and RoofPP plastic front body and rear body; FRP roof
WindshieldOrganic plastic windshield, one-piece
Roof supportsCarbon Steel, powder coated
Backrest and SeatReborn Sponge, artificial leather + plastic armrest
FloorGalvanized Steel plate and anti-slip rubber floor mat
DashboardPlastic in black, with 4 cup holders, 2 glove storage box, forward/reverse switch, battery capacity indicator, ignition key
Side trimAluminum alloy
Sider mirror2pcs, foldable
Electric System
Lighting system and hornAll LED lights, 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with 20A voltage reducer (converting from 72V to 12V), electric horn.
Backup Buzzer12V
ChargerSmart charger, input 110V-240V~50Hz-60Hz, output 72V, 20A
Steering, Brake, Transmission and Suspension
Steering SystemSingle-stage rack and pinion steering system, automatic rocker compensating function
Brake systemRear wheel mechanical brake, foot activated parking brake
AcceleratorStepless speed change
Driving modeRear axle two stage deceleration, motor direct driving
Rear axleIntegrated, Gear ratio12.49:1
Suspension systemFront and rear plate leaf spring + cylinder hydraulic shock absorber




Packaging & Shipping


1. Delivery date: 15 days for mass producing
2. 1*20'GP fit 8 units.1*40'HQ fit 21 units.
3. Asia: 3-7 days to arrive; Other : 15-30 days to arrive.


Our Service

We provide 12 months warranty to the electric vehicles from the shipping date. We will cover the labor cost for any warranty issue.

Why choose us?

a. Delivery in Time
b. High quality with reasonable price
c. Quick response to all your inquiry for 5 minutes.
d. Provide customers with high quality products and efficient service.
